Mac mini (Mid 2007)

Introduced: August 2007
Terminated: n/a

Description

The Mac mini (Mid 2007) was a speed bump on the previous models.  Now with the Intel Core2 Duo processors, the speed was higher and the hard drives were bigger.  The low-end ran at 1.83Ghz.  It still had a Combo drive and an 80Gb hard drive.  The high-end configuration ran at 2.0Ghz.  It still had a SuperDrive and now had a 120Gb hard drive.  Both configurations had four USB ports, optical audio in/out, Airport Extreme and Bluetooth.  They also included the Apple Remote.

History

The Mac mini (Late 2006) was an upgrade on the previously released models and brought both configurations up to the Core2 Duo standard.  The price remained the same

Photos

Mac mini (Mid 2007)

Specifications

Processor: Intel Core 2 Duo (“Merom”)
Processor Speed: 1.83 or 2.0 GHz
Benchmarks: 1.83 GHz: 2473, 2.0 GHz: 2668
Cache: 2 MB (1.83 GHz) 4 MB (2.0 GHz) shared
System Bus: 667 MHz
Hard Drive: 80, 120 (1.83 GHz only), or 160 GB 5400-rpm
Media: Slot-loading Combo drive (DVD-ROM/CD-RW) or Slot-loading SuperDrive (DVD±R DL/DVD±RW/CD-RW)
Peripherals: Apple Remote
Weight and Dimensions (US): 2.9 lbs., 2” H x 6.5” W x 6.5” D
Weight and Dimensions (Metric): 1.31 kg, 5.08 cm H x 16.51 cm W x 16.51 cm D
Original Mac OS: Mac OS X 10.4.10 (8R3014)
Later Mac OS:—
Maximum Mac OS: Latest release of Mac OS X
Hardware Test: AHT 3A129
Firmware: Intel Extensible Firmware Interface (EFI)
Firmware Update: None
Logicboard RAM: None
Maximum RAM: 2.0 GB
Type of RAM Slots: 2 - 200-pin PC2-5300 (667MHz) DDR2 SO-DIMM
Minimum RAM Speed:—
Interleaving Support: Yes
Graphics Card: Intel Graphics Media Accelerator (GMA) 950
ATI Card Model:—
Graphics Connection:—
Graphics Memory: 64 MB DDR2 (shared with main memory, minimum memory usage is 80 MB)
Built-in Display: None
Resolutions: DVI output up to 1920 x 1200 or VGA output up to 1920 x 1080
Display Connection: DVI (VGA or S-video with adapter)
Expansion Slots: None
Hard Drive Bus: 1.5 Gbps Serial ATA (SATA)
Large Drive Support: Yes (128 GB or larger per drive)
Backup Battery: 3 V Lithium (922-6476)
Max Watts: 110W
Line Voltage: 100-240V AC
AirPort: Built-in AirPort Extreme card (802.11b/g)
Bluetooth: Built-in Bluetooth 2.0 + EDR
Ethernet: 10/100/1000BASE-T (RJ-45) (support for jumbo frames)
Infrared: 1 - For Apple Remote only
Modem: Optional Apple USB Modem (MA034Z/A)
USB: 4 - 480 MBit/s
FireWire: 1 - 400 MBit/s (8W)
Audio In: 1 - 3.5-mm analog/optical input jack
Audio Out: 1 - 3.5-mm analog/optical combo jack, 1 - Built-in speaker

Timeline

The Mac mini (Mid 2007) was introduced in August 2007.
